Chroma  |  SKU: chr61609

Chroma 61609 Programmable AC Power Supply 0-350V, 15Hz-2KHz / 6KVA, 1-3Ø


The 61600 series is cheaper than the 61500 series. The latter allows users to define different harmonic components and analyze harmonics and distorted waveforms . By applying this advanced function, users can program a scan frequency to a given voltage and thus analyze the resonance points of the UUT.

Description



MODEL 61609
Power Rating 6000VA
Phase 1 or 3 selectable
Voltage Range 0-175V/0-350V/Auto
Frequency 15Hz~2000Hz
Parallel Capability Available




    Features

    61500/61600 series features:

    • 5U high power density design
    • Single-phase or three-phase output selectable
    • Programmable slew rate setting for changing voltage and frequency
    • Programmable voltage and current limit
    • High output current crest factor for inrush current testing
    • Turn on and turn off phase angle control
    • TTL signal which indicates output transient
    • LIST, PULSE, STEP mode functions for testing Power Line Disturbance (PLD) simulation (61500 series only)
    • Voltage dips, short interruption, and voltage variation simulation
    • Harmonics and inter-harmonics waveform synthesizer (61500 series only)
    • Comprehensive measurement capability including current harmonics (61500 series only)
    • Analog programmable interfaces
    • Remote interface: GPIB, RS-232, USB, and Ethernet
    • Higher output power capability by implementing master-slave parallel output function
