GW Instek  |  SKU: 01PS430310GS

GW Instek GPS-4303

Regular price €391,00
Tax included Shipping calculated at checkout.

The GPS-x303 series of linear programmable power supplies is available in 2-4 channels , with maximum outputs of 180W and 200W. Overload protection , reverse polarity and an output on/off switch protect the GPS series and their load from unexpected conditions. A 'high regulation capability (0.01% + 3mV) and low ripple/noise value (<1mVrms, 5Hz ~ 1MHz) are typical for the two channels in constant voltage mode. Automatic control of the speed of the cooling fan according to load conditions allows its noise to be minimized, ensuring quiet operation. The GPS-x303 series are the ideal solution for benchtop applications. The power supplies are portable , lightweight , economical and offer multiple outputs.

Model

Description



model GPS-4303
200W
SKU 01PS430310GS
CH1 0-30V 0-3A
CH2 0-30V 0-3A
CH3 2. 2-5.2V
CH4 8-15V
Series Connection Voltage Range
0-60V Applicable between CH1 and CH2
Range of Current parallel connection
0-6A Applicable between CH1 and CH2



Features

  • 4 Independent Isolated Outputs
  • Four "3 Digits" LED Displays
  • 0.01% Load and Line Regulation
  • Low Ripple and Noise
  • Tracking Operation and Auto Series/Parallel Operation
  • Output ON/OFF Switch
  • Output Voltage and Current Setting When Output Disable
  • Fan Speed Control Circuit to Minimize Fan Noise
  • Over Load and Reverse Polarity Protection
  • Optional European Jack Type Terminal
