Jtag Technologies  |  SKU: JTL-CLIP

Jtag Technologies: JTAG Live Clip

€535,00
Tax included Shipping calculated at checkout.

Clip is a vector-based update for creating and saving board-level tests. It features unlimited bit depth and width. Clip's logic analyzer-like waveform display shows you what is happening with the signals on your board. Use Clip's "Compare on" and "Set breakpoint" options for complete control over the execution.

Description





















Features
  • Waveform display of sample results
  • Unlimited keys and drives

"Clip" details- Execution of complex vector-based cluster tests by stimulating and reading back individual pins or pin groups.- Display in waveform possible.- Learning the cluster from the Golden Board with subsequent comparison with other modules.- Single step and auto-repeat function- Via drag & drop

Manuals

Jtag clip datasheet

Jtag live overview
