GW Instek GPE-4323

📢 OFFER VALID FROM 15 APRIL 2026 to 30 JUNE 2026

In the market, the GPE-X323 series is recognized as a high-resolution series. It is made according to the highest production quality. The GPE-X323 series offers two output powers 192W to 217W. The three output channels are isolated and independent (GPE-X323). These power supplies feature high resolution, low noise, high reliability, key lock function and compact size.
The GPE-X323 series establishes an excellent solution for high quality and cost.

Model

Description

Offer valid from 15 April 2026 to 30 June 2026

model GPE-4323
Power max 212W
SKU 01GP432310GS
Number of Channels CH1 [0-32V 0-3A]
CH2 [0-32V 0-3A]
CH3 [0-5V 0-1A]
CH4 [0-15V 0-1A]
CH1+CH2 Series Connection Voltage Range
 0-64V
Range of Current parallel connection CH1+CH2
 0-6A

Features

GPE-X323 series features

  • 1 / 2 / 3 / 4 Independent Isolated Output
  • 4.3 Inch LCD Display
  • Setting & Read back Resolution 100mV / 10mA (*1)
  • Output ON/OFF
  • Analog Control (Remote I/O) for Output ON / OFF
  • Set View function for checking an original V / I setting during output on
  • Key Lock Function
  • Tracking series and parallel operation
  • Smart cooling fan achieving low noise
  • Optional European Jack Type Terminal

Manuals

GPE-x323_specs
GPE-x323_datasheet
