Rigol  |  SKU: DSA875-TG
20% off

Rigol DSA875-TG 9kHz - 7.5GHz spectrum analyzer (tracking generator)

Rigol EMI Promotion
Get the EMI-DSA800 option for free with the purchase of a new device, serie DSA800. (Valid until June 30, 2026)

Ultra-compact and lightweight spectrum analyzer with excellent performance. Digital IF(intermediate frequency) technology ensures reliability and performance to meet most RF applications.
Large high-resolution display, vast number of functions for wide use and maximum flexibility.

7.5GHz tracking generator included.

Care information

Display general product information or specific product information using metafields.

Delivery and Shipping

Add some general information about your delivery and shipping policies.

Description

Rigol EMI Promotion
Get the EMI-DSA800 option for free with the purchase of a new device, serie DSA800. (Valid until June 30, 2026)

Model

DSA875-TG

Frequency

Frequency Range

9 kHz to 7.5 GHz

Frequency Resolution

1 Hz

SSB Phase Noise

20° to 30°, fc=1GHz

Carrier Offset

10kHz

<-98dBc/Hz

100kHz

<-100dBc/Hz (typ.)

1MHz

<-120dBc/Hz (typ.)

Bandwidths

Resolution Bandwidth (-3dB)

10 Hz to 1 MHz, in 1-3-10 sequence

Displayed Average Noise Level(DANL)

0 dB RF Attenuation, RBW=VBW=100Hz, Sample Detector, Trace Average ≥ 50, Tracking generator OFF, normalized to 1Hz, 20° to 30° ,input terminated 50Ω, PA On

5 MHz to 1.5GHz

<-157dBm, <-161dBm (typ.)

1.5 GHz to 3.2 GHz

3.2 GHz to 6 GHz

<-153dBm, <-157dBm (typ.)

6 GHz to 7.5 GHz

<-148dBm, <-152dBm (typ.)



Features

DSA800 series features

  • All-Digital IF Technology
  • Frequency Range from 9 kHz up to 7.5 GHz
  • Min. -161 dBm Displayed Average Noise Level (Typ.)
  • Min. < -98 dBc/Hz @ 10 kHz Offset Phase Noise
  • Level Measurement Uncertainty < 0.8 dB
  • 10 Hz Minimum Resolution Bandwidth
  • Up to 7.5 GHz Tracking Generator (DSA8XX/E-TG)
  • Advanced Measurement Functions (Opt.)
  • EMI Filter & Quasi-Peak Detector Kit (Opt.)
  • VSWR Measurement Kit (Opt.)
  • PC Software (Opt.)
  • Optional RF TX/RX Training Kit
  • Optional RF Accessories (Cable, Adaptor, Attenuator, Bridge ...)
  • Complete Connectivity: LAN (LXI), USB Host & Device, GPIB (Opt.)
  • 8 Inch WVGA (800x480) Display
  • Compact Size, Light Weight Design

Manuals

DSA800 series Datasheet

DSA800 Series UserGuide
