EMC pre-compliance testing checks a product for electromagnetic emissions and immunity problems before it goes to a formal, accredited certification test. It will not produce a certificate of compliance, but it catches the problems that would otherwise surface, expensively, at the certification lab: excess conducted or radiated emissions, insufficient immunity to external disturbances, or a design detail that fails a specific limit line.
Why test before the real test
Formal EMC certification is expensive, it is booked in advance, and a failure means redesigning the product and paying for a repeat test. Pre-compliance testing moves that discovery earlier, into the design and prototyping phase, where a fix is a matter of routing a trace differently or adding a ferrite, not redesigning a board that has already gone to certification.
Conducted emissions: what a LISN actually measures
Conducted emissions are electrical noise that travels back through a product's power cable into the mains network. A «LISN», Line Impedance Stabilization Network, such as the TekBox TBL5016-3-EU, sits between the product under test and the mains supply. It presents a known, standardised impedance to the product, and gives a measurement point where a spectrum analyzer can read the actual noise the product injects onto the line, following the CISPR 16-1-2 measurement method.
Radiated emissions: measuring what the product broadcasts
Radiated emissions are the electromagnetic energy a product radiates directly through the air, rather than through its cables. Pre-compliance measurements typically use a biconical or log periodic antenna together with a spectrum analyzer, in an open area or a shielded room, to estimate whether the product is likely to pass the far more controlled measurement performed at an accredited test site.
Immunity: testing resilience, not just emissions
The other half of EMC is immunity: whether a product keeps working correctly when exposed to external electromagnetic disturbances. Pre-compliance immunity testing typically injects a controlled RF field or a conducted disturbance and checks whether the product under test continues to behave as expected, rather than resetting, glitching, or producing incorrect readings.
What pre-compliance testing does not replace
A pre-compliance result is not a certificate, and it should not be presented as one. Formal compliance testing at an accredited laboratory, following the exact CISPR or IEC procedures and using calibrated, traceable setups, remains the only test that carries legal weight for CE marking or equivalent regulatory requirements. Pre-compliance is a design tool, not a substitute for that final step.
ALLdata's role
ALLdata, together with TekBox and Rigol, supplies complete pre-compliance setups, from LISNs and antennas to the spectrum analyzer and control software, matched to the standards a given product actually needs to meet. A ready packaged option, the RIGOL EMC Pretest Solution, bundles the core instruments needed to get started.
Planning your first pre-compliance setup, or need to check whether your current one still covers the standards you test against? Talk to an ALLdata engineer, or browse our EMC test systems.
