Rigol  |  SKU: DG5508 Pro
10% off

Rigol DG5508 Pro: 500 MHz bandwidth 8 CHs

Rigol BND Promotion
Get the DG5000 Pro-BND option for free with the purchase of a new device, serie DG5000 Pro. (Valid until June 30, 2026)

With a sampling rate of up to 2.5 GSa/s and an arbitrary waveform length of 64 Mpts/CH (128 Mpts/CH optional), the DG5000 Pro Series Arbitrary Waveform/Function Generator is an all-in-one generator integrating a function generator, arbitrary waveform generator, noise generator, pulse generator, harmonic generator, and analog/digital modulator. It is a multifunctional, cost-effective, dual-channel arbitrary waveform/function generator.

Description

Rigol BND Promotion
Get the DG5000 Pro-BND option for free with the purchase of a new device, serie DG5000 Pro. (Valid until June 30, 2026)

Model DG5508Pro
Analog Bandwidth 500 MHz
Channels
8 both isolated from the Ground
Vertical Resolution
16 bits
Sample Rate
2.5 GSa/s
Arbitrary Waveform Lenght
64 Mpts/CH (standard) , 128 Mpts/CH (optional)
Min. Rise Time
 0.8 ns
Dimensions (W×H×D)
 358 mm (W) x 215 mm (H) x 122 mm (D)








Features

Manuals

DG5000_Pro_Datasheet

DG5000_Pro_QuickGuide
