Rigol  |  SKU: DSG821

Rigol DSG821 2.10GHz RF Generator

Excellent value for money RF signal generator.

Bandwidth from 9kHz to 2.1GHz, AM, FM, phase and pulse modulation.



Description

Model

DSG821

Frequency

9 kHz to 2.1 GHz

Phase Noise (typical)

Up to -112 dBc/Hz

Amplitude Accuracy

Higher level up to 0.5 dB (typical)

Connectivity

LXI-C, USB

Modulation

Complete AM/FM/ØM analog modulation functions
I/Q Modulation only available for DSG821A and DSG836A
I/Q Baseband Generator only available for DSG821A and DSG836A

Pulse Train Generator , Pulse Modulation , Pulse Generator

Option

High Stable Reference Clock

Option

























Features

Highly cost-effective economical RF signal generator

  • Up to -105 dBc/Hz (typical) phase noise
  • Up to +20 dBm (typical) maximum output power
  • Higher level of amplitude accuracy, up to 0.5 dB (typical)
  • Superb signal stability

Functions almost matching those of high-level RF signal generators

  • Flexible frequency and amplitude sweep functions
  • Complete AM/FM/ØM analog modulation functions
  • Standard LF output function
  • Powerful pulse modulation function
  • System flatness calibration function
  • Simple and easy to operate

Special design ensuring its reliability and durability

  • Use electronic attenuator to avoid wearing
  • Specially designed protection functions
  • Digital ALC circuit
  • Simple structure

Smallest in size among the like products

  • Occupy the least workbench space
  • Occupy less rack space
  • Light weight; the handle offers comfortable grip

Manuals

Datasheet DSG800 Series

DSG800 Series UserGuide
