GW Instek  |  SKU: 01PR11H3D0GS

GW Instek GPR-11H30D

The GPR-H series consists of single output linear DC power supplies from 240 to 375 W. From 8 to 300 V, the GPR-H series is available in different configurations to meet different requirements. To protect loads, the GPR-H series has effective protection measures with overload and reverse polarity protection. The 'excellent regulation and low ripple/noise make the GPR-H series particularly suitable for high-end bench applications where good accuracy is required.

Description
model GPR-11H30D
330W
SKU 01PR11H3D0GS
OUTPUT VOLTS (V) 0 ~ 110V
OUTPUT AMPS (A) 0 ~ 3A



Series Models :

Output Watts
(W)		 Output Volts
(V)		 Output Amps
(A)
GPR-1820HD 360W 0 ~ 18 0 ~ 20
GPR-3510HD 350W 0 ~ 35 0 ~ 10
GPR-7550D 375W 0 ~ 75 0 ~ 5
GPR-11H30D 330W 0 ~ 110 0 ~ 3

    Features
    • 0.01% High Regulation
    • Constant Voltage and Constant Current Operation
    • Internal Select for Continuous or Dynamic Load
    • Low Ripple and Noise
    • Overload and Reverse Polarity Protection
    • 3 1/2 Digit 0.5" LED Display
    • Internal Select for Continuous or Dynamic Load (for GPR-3510HD/GPR-6060D/GPR-7550D)

    Manuals

    GPR-H_specifications
    GPR-H_user_manual
