GW Instek  |  SKU: 01PR306D00GS

GW Instek GPR-3060D

The GPR-M series consists of single output, 180 W linear DC power supplies. The series has the same functions as the GPR-H series but meets the specific demand for low power requirements. Like the GPR-H series, the GPR-M series is particularly suitable for high-end precision benchtop applications. Low load and linear regulation for both constant voltage and constant current modes ensure reliable and desired output. Overload and reverse polarity protection as well as internal selection for dynamic or constant load are provided as standard.

Description
model GPR-3060D
180W
SKU 01PR306D00GS
OUTPUT VOLTS (V) 0 ~ 30V
OUTPUT AMPS (A) 0 ~ 6A

Series Models：
Output Watts
(W)		 Output Volts
(V)		 Output Amps
(A)
GPR-1810HD 180W 0 ~ 18 0 ~ 10
GPR-3060D 180W 0 ~ 30 0 ~ 6
GPR-6030D 180W 0 ~ 60 0 ~ 3



    Features
    • 0.01% High Regulation
    • Constant Voltage and Constant Current Operation
    • Internal Select for Continuous or Dynamic Load
    • Low Ripple and Noise
    • Overload and Reverse Polarity Protection
    • 3 1/2 Digit 0.5" LED Display

    Manuals

    GPR-M_specifications

    GPR-M_user_manual
