- Voltage range : 30V/40V/80V/160V/250V/800V
- Output power : 360W-1080W
- Various voltage/current combinations
- CV/CC priority ; particularly useful function in leds and battery testing
- Adjustable slew rate
- Series connection : up to two units for models (30V/40V/80V/160V)
- Parallel connection : up to three units for models (30V/40V/80V/160V/250V/800V)
- High efficiency and high power density
- 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W/720W/1080W
- Standard communication interfaces : LAN,USB,Analog
- Optional Communication Interfaces : GPIB-USB Adaptor, RS232-USB Cable
- LabView Driver
ACCESSORIES
CD-ROM x1(Programming Manual, User Manual)
Power Cord x1(Region dependent)
GTL-123 Test Lead x (for PSW 30V/80V/160V models)
GTL-240 USB Cable "L" Type x1
PSW-004 Basic Accessories Kit x1(for PSW 30V/80V/160V models)
PSW-008 Basic Accessories Kit x1(for PSW 250V/800V models)
PSW-009 Output terminal cover(for 30V/80V/160V models)
PSW-011 Output terminal cover(for PSW 250V/800V models)
PSW-012 High voltage output terminal(for 250V/800V models)
OPTIONAL ACCESSORIES
PSW-001 Accessory Kit
PSW-002 Simple IDC Tool
PSW-003 Contact Removal Tool
PSW-005 Cable for 2 Units of PSW-Series in series mode connection(for PSW 30V/80V/160V models)
PSW-006 Cable for 2 Units of PSW-Series in parallel mode connection
PSW-007 Cable for 3 Units of PSW-Series in parallel mode connection
PSW-010 Large filter (for PSW 720W/1080W models)
GUG-001 GPIB to USB Adaptor
GRA-410-J Rack Mount Kit(JIS)
GRA-410-E Rack Mount Kit(KIA)
GET-001 Extended Terminal with max. 30A(for PSW 30V/80V/160V models)
GET-002 Extended Terminal with max. 10A(for PSW 250V/800V models)
GET-005 Extended European Terminal with max. 20A(for PSW 30V/80V/160V models)
GTL-130 Test Lea: 2x red, 2x black(for PSW 250V/800V models)
GTL-248 GPIB Cable, 2000mm
GTL-250 GPIB Cable, 600mm
GTL-251 USB-GPIB Adapter, GPIB-USB-HS, USB 2.0, Hi-Speed USB compliance, 2000mm
GUR-001A USB TO RS-232 Cable, 3000mm
The ability to set CV/CC priority is useful for DUT protection.
Adjusting the slew/rate makes it easier to verify the operating characteristic of a DUT by allowing the output voltage or output current to be changed at a specific time. In addition, to prevent inrush current from damaging high-current devices, a smooth and slow voltage transition during turn-on and turn-off can significantly reduce the inrush current and prevent device damage.
The series provides OVP and OCP protection controls. Their levels are selectable . The default level is set at 110% of the voltage and current ratings of the power supply. When a protection level is activated the output is immediately turned off.
