JTAG Live Studio is your complete JTAG / boundary-scan solution for testing, debugging and programming your boards. Based on the standard JTAG Live platform that now includes an automated scanpath builder, Studio adds JTAG Live Buzz, BuzzPlus, AutoBuzz, Clip, Script, JAM, STAPL and SVF PLUS a JTAG Live controller.With the latest version of AutoBuzz, interconnects can be tested using a comparison with a known working board or by learning boundary-scan pin connections from a CAD-derived netlist.You can create reusable clusters tests and flash programming actions in Python using Script.You can also include IC-level testing by adding low-cost CoreCommander options that can control IC cores and/or FPGA gate array connection.JTAGLive Studio contents:
consisting of the Software modules Buzz, Buzz+, AutoBuzz, Clip, Script, SVF Player and the JTAGLive Controller.
- Controller drivers for JTAG Technologies Controller, Altera, Xilinx, FTDI 2232.
- BSDL syntax and semantics checking.
- 1 Year SW maintenance, following years 20% per year.
- MAC address based Permanent Node Locked License.
__________________________________________________________________________
Software modules details:
"Buzz " to learn and check the chain, sample the value of a Bscan pin while the target is running.
"BuzzPlus" to find the those Bscan pins that are connected to a Bscan pin of your choice.
"Clip" for stimulating any number of Bscan pins with manually entered values or with a waking 1 or 0 pattern and simultaneously monitoring another group Bscan pins
"AutoBuzz " to learn all Bscan to Bscan connections of a target and compare the found ones against another board or against a given netlist;
"Script"; Python based scripting for:
- Cluster testing;
- e.g. mixed singals, if/else, value calculation, I²C ect. (more examples on our homepage - Forum)
- Execution of a script with all tasks for production
__________________________________________________________________________
JTAGLive Boundary Scan Controller:
for testing, PLD programming and small FLASH programming applications:
- 1 TAP's;
- programmable output voltage from 1.5 V to 3.6 V in steps of 0.1V
- programmable input threshold from 0 V to 4.1 V in steps of 0.1 V
- Powered from USB bus
- Compatible with USB 2.0 full speed (12 Mbit/s)
- Programmable burst TCK: 100 Hz - 6 MHz
- Scan Function Library
