Rigol  |  SKU: DM3068

Rigol DM3068 6 and 1/2 digit multimeter

DM3068 is a digital multimeter designed with 6 ½ digits readings resolution especially fitting to the needs of high-precision, multifunction and automatic measurement. It adopts many today's new technologies to achieve high performance, abundant features in the same class. It's designed to aim at the requirements of the largest DMM market from the research, education,industrial electronics,consumer electronics and automotive industries with its innovative technology,industry leading specifications,powerful measurement functions and
broad analysis capabilities.

DM3068 is a Multifunction digital multimeter. Resolution 6½ digits, DC voltage accuracy (1 year) 0.0035%, DC voltage range -1000 V ~ 1000 V, max sampling rate 10KSa/s.

Description
Measurement Function
Range
Frequency Range/Test Current
Accuracy: 1 Year ± (%of reading +%of range)
DC Voltage
200 mV - 1000 V

0.0035+0.0005
DC Current
200 uA - 10 A

0.050+0.005
AC Voltage (RMS)
200 mV - 750 V

0.06+0.03
AC Current (RMS)
20 mA - 10 A

0.10+0.04
Resistance(2-wire and 4-wire)
200 Ω - 100 MΩ

0.010+0.001
Capacitance
2 nF - 10000 uF

1 + 0.5
Diode
2.0 V


Continuity
2 kΩ


Frequency and Period
200 mV - 750 V
3 Hz - 1 MHz / 1 usec - 0.33 sec
0.007





Features

• Real 6 ½ digits readings resolution (2,200,000 Count)
• Up to 10 K rdgs/s of measurement speed and 512 K rdgs Volatile Memory
• True-RMS AC Voltage and Current measurement
• Built-in 10 groups data storage,10 groups setup storage
• Built-in Thermcouple compensate in Cold terminal,
support customized any sensor measurement and 3 types of
temperature sensors:TC,RTD and THERM
• Clone or backup all the configurations within instrument into otherDM3068 via U-disc
• UltraSensor software: Easy, convenient and flexible to support
"Any sensor" measurements
• Real time Trend and Histogram Display functions
• Standard interface: USB Device, USB Host, LAN, RS-232, GPIB,
support U-disc storage and Web remote control (LXI-C)
• Remote control with SCPI commands
• 256 × 64 LCD
• Support double display, waveform display, Chinese and English menu
• Push-help makes information acquire more easier
• File management (support for U-disc and local storage)

Manuals

Datasheet DM3068

UserGuide DM3068
